Find out more9, 12 and 16 inch HybridTouch chartplotters with RealVision 3D and 1kW CHIRP sonar technology
Available with RealVision 3D, 1kW CHIRP sonar, and Raymarine HybridTouch control, Axiom Pro RVX is the standard for networked chartplotter displays. And with a blazing fast quad core processor, a super bright IPS display, and the smart LightHouse OS, it delivers a fluid and intuitive navigation experience.
Axiom Pro RVX is easy to expand into an advanced navigation network that includes multiple Axiom displays, CHIRP radar, Evolution autopilot, FLIR thermal night vision technology, and more.
Axiom Pro’s quad core processor delivers instantaneous response and the ability to run multiple apps simultaneously without any slowdowns.
Keep an eye on everything onboard from the helm. Axiom Pro supports both video over IP and analog cameras.
Raymarine optical bonding technology and IPS display panels give you stunning color, clarity, and contrast in all lighting conditions. Plus, Axiom Pro looks great even through polarized sunglasses.
Combine Axiom Pro with the FLIR thermal cameras and enjoy ClearCruiseTM IR object detection. Axiom Pro will alert you automatically to hazards in the vessel’s path.
Axiom Pro works with Raymarine's full lineup of Cyclone and Quantum solid-state radars for all-weather collision avoidance and advanced bird identification technology.
Axiom Pro is ready to network with all the latest electronics using standard NMEA2000 and NMEA0183 connectivity.
HybridTouch™ - Your choice of simple tablet like touch screen interaction or confident keypad control in rough seas.
LightHouse OS - Fast, fluid and easy to learn. The Lighthouse operating system interface is uncluttered and easy to personalize for your style of boating.
Custom Key - Get instant access to your favorite function with Axiom Pro’s user-programmable Custom Key.
Axiom Pro RVX are available in 9, 12 or 16-inch screen sizes.
16" Display
RealVision 3D & 1kW CHIRP Sonar Built In
16" Display
RealVision 3D & 1kW CHIRP Sonar Built In
Includes blank Navionics chart card for one region download
| Physical | |
|---|---|
| Dimensions (Trunnion mounted) | Axiom Pro 9: Height: 186.2 mm (7.33 in), Width: 329.5 mm (12.97 in), Depth (including cables): 234.9 mm (9.25 in) Axiom Pro 12: Height: 246.13 mm (9.69 in), Width: 388.5 mm (15.3 in), Depth (including cables): 233.4 mm (9.18 in) |
| Dimensions (Surface/Flush mounted) | Axiom Pro 9: Height: 173.79 mm (6.84 in), Width: 299.32 mm (11.78 in), Depth (including cables): 234.9 mm (9.25 in) Axiom Pro 12: Height: 222.8 mm (8.77 in), Width: 358.03 mm (14.1 in), Depth (including cables): 233.4 mm (9.18 in) Axiom Pro 16: Height: 258 mm (10.16 in), Width: 452.02 mm (17.8 in), Depth (including cables): 240.4 mm (9.46 in) |
| Accessory connection | USB Micro B |
| Ethernet connection | 2 RayNet (10/100/1,000 Mbits/s) ports |
| NMEA 0183 connection | Port 1: Input and output 4,800 or 38,400 baud rate, Port 2: Input only 4,800 or 38,400 baud rate |
| External storage | 2 front mounted MicroSDXC card slots |
| NMEA 2000 connection | DeviceNet connector |
| Wireless connections | Bluetooth: V4.0 Wi-Fi: 802.11/b/g/n |
| Internal storage | 16GB Solid State |
| Transducer connection | 25 pin RealVision type connector. Requires the A80490 adaptor cable for CPT-S style transducers |
| LCD | |
|---|---|
| Size (diagonal) | Axiom Pro 9: 9.0" Axiom Pro 12: 12.1" Axiom Pro 16: 15.6" |
| Ratio | Axiom Pro 9: 16:9 Axiom Pro 12: 16:9 Axiom Pro 16: 16:10 |
| Resolution | Axiom 2 Pro 9: 1280 x 720 HD Axiom 2 Pro 12: 1280 x 800 WXGA Axiom 2 Pro 16: 1920 x 1080 FHD |
| Viewing angle | Top 88° / Bottom 88° / Left 88° / Right 88° |
| Type | IPS (In-Plane Switching) |
| Color depth | 24-bit |
| Illumination | Axiom 2 Pro 9 1300 nits / 1300 cd/m2 |
| Number of simultaneous touches | 1 to 16 |
| Power | |
|---|---|
| Power consumption @ 12 V dc | Axiom Pro 9: 33.12 W Axiom Pro 12: 29.88 W Axiom Pro 16: 42.36 W |
| Power consumption @ 24 V dc | Axiom Pro 9: 30.96 W Axiom Pro 12: 28.8 W Axiom Pro 16: 40.8 W |
| Operating voltage range | 8 V dc to 32 V dc |
| Off current @ 24 V dc | 18 mA (0.43 W) |
| Nominal supply voltage | 12 V dc / 24 V dc |
| Off current @ 12 V dc | 11 mA (0.13 W) |
| LEN (NMEA 2000 Load Equivalency Number) | 1 |
| Current | 5 A |
| Fuse rating | 15 A |
| Sonar | |
|---|---|
| RealVision Depth range | 25 pin RealVision type connector: High CHIRP conical sonar: 0.6 m (2 ft) to 274 m (900 ft), DownVision: 0.6 m (2 ft) to 183 m (600 ft), SideVision: 0.6 m (2 ft) to 91 m (300 ft) , RealVision 3D: 0.6 m (2 ft) to 91 m (300 ft) |
| 1 kW Depth range | 11 pin 1kW connector: : 0.9 m (3 ft) to 914.4 m (3,000 ft) (In optimum conditions using a 1kW transducer) |
| Environmental | |
|---|---|
| Operating temperature | -25°C to +55°C (-13°F to 131°F) |
| Storage temperature | -30°C to +70°C (-22°F to 158°F) |
| Relative humidity | Up to 93% @ 40°C (104°F) |
| Waterproof rating | IPx6, IPx7 |
| GNSS (GPS) | |
|---|---|
| Position Accuracy | Without SBAS: ≤ 15 metres 95% of the time, With SBAS: ≤ 5 metres 95% of the time |
| Geodetic Datum | WGS-84 (alternatives can be selected on the MFD) |
| Satellite Differential Type (SBAS) | WAAS (United States), EGNOS (Europe), MSAS (Japan), GAGAN (India), QZSS (Japan) |
| Channels | Track up to 28 satellites simultaneously |
| Antenna | Internal - Ceramic chip mounted near top of unit |
| GNSS compatibility | GPS, Galileo, GLONASS, Beidou |
| Almanac Update | Automatic |
| Signal Acquisition | Automatic |
| Receiver IC Sensitivity | 165 dBm (Tracking), 160 dBm (Acquisition), 148 dBm (Cold start) |
| Operating frequency | 1574 MHz to 1605 MHz |
| Refresh rate | 10 Hz (10 times per second) |
| Time to first fix from cold start | < 2 minutes |
| 1 | MFD (Chartplotter) |
| 2 | Front bezel pieces and Upper keypad |
| 3 | Panel mount gasket |
| 4 | Suncover |
| 5 | Trunnion bracket |
| 6 | Trunnion knobs x 2 |
| 7 | Fixings (M4x40 pan head bolt x 4, M4 Nylock nut x 4 and M4 washer x 4) |
| 8 | Optional grounding connection (Screw (M3x5), Spring washer (M3), Crimp terminal (M3)) |
| 9 | Power/Video/NMEA 0183 cable 1.5 m (4.92 ft) |
| 10 | Documentation |
| 11 | RayNet (Female) to RayNet (Female) network cable 2 m (6.56 ft) |
| 12 | DeviceNet to SeaTalkng adaptor cable 120 mm (4.7 in) |
