| Environmental | |
|---|---|
| Relative humidity | Up to 95% |
| Waterproof rating | IPx6, IPx7 |
| Storage temperature | -30°C to +70°C (-22°F to 158°F) |
| Operating temperature | 0°C to 55°C (32°F to 131°F) |
| Physical | |
|---|---|
| Dimensions | Height: 162 mm (6.4 in), Width: 225 mm (8.9 in), Depth: 72 mm (2.8 in) |
| Weight | 0.6 kg (1.32 lbs) |
| Conformance | |
|---|---|
| Standards | EN 60945:2002, EMC Directive 2014/30/EU, Australia and New Zealand: C-Tick, Compliance Level 2 |
| Power | |
|---|---|
| Power consumption | 5.6 W (maximum) |
| Fuse rating | 5 A |
| Nominal supply voltage | 12 V dc / 24 V dc |
| Operating voltage range | 10.8 V dc to 31.2 V dc |
| Current | 1 A peak |
| Sonar | |
|---|---|
| Depth range | Up to 183 m (600 ft) (Range performance is dependent on many factors, including water quality, transducer installation, and reflectivity of targets and structure.) |
| Beam coverage | Port and starboard-facing - wide (port / starboard) and thin (fore / aft) |
| Channels | CHIRP port and starboard |
| 1 | Sonar module |
| 2 | Documentation |
| 3 | Fixing screws x 4 |
| 4 | Power cable 1.5 m (5 ft) |
